GB B860M D3HP

Марка: GIGABYTE
Код:

B860M D3HP / B860M D3HP 1.0

Изпрати на приятел

Оцени продукта

Сравни

256.75 лв. €131.27

Manufacturer:

GIGABYTE
OS:

Support for Windows 11 64-bit;Support for Windows 10 64-bit
Memory type:

Support for DDR5 9066(O.C) / 8800(O.C) / 8600(O.C) / 8400(O.C) / 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 5600 MT/s memory modules;4 x D...
Graphics:

Integrated Graphics Processor-Intel® HD Graphics support:;- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz;* Support for HDMI 2.1 version and HDCP 2.3.;- 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz;* Support...
Audio:

Realtek® Audio CODEC;High Definition Audio;2/4/5.1/7.1-channel
LAN:

Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Expansion Slots:

CPU:;- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16;* The PCIEX16 slot can only support a graphics card or an NVMe SSD.;Chipset:;- 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1
I/O:

iTE® I/O Controller Chip
Form Factor:

Micro ATX Form Factor; 24.4cm x 24.4cm
CPU's supported:

LGA1851 socket: Support for Intel® Core™ Ultra Processors;L3 cache varies with CPU
Chipset:

Intel® B860 Express Chipset
Storage:

CPU:;- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support)(M2A_CPU);Chipset:;- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support)(M2Q_SB);- 4 x SATA 6Gb/s connectors;RAID 0, RAID 1, RAID 5, and RAID 10 suppo...
Connectors:

1 x 24-pin ATX main power connector;1 x 8-pin ATX 12V power connector;1 x CPU fan header;1 x CPU fan/water cooling pump header;1 x system fan header;1 x system fan/water cooling pump header;2 x addressable RGB Gen2 LED strip headers;1 x RGB LED strip h...
BIOS:

1 x 256 Mbit flash;Use of licensed AMI UEFI BIOS;PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Features:

Support for GIGABYTE Control Center (GCC);Support for Q-Flash;Support for Smart Backup
USB:

Chipset:;- 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header;- 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header);- 3 x USB 2.0/1.1 ports on the back panel;Chi...
